High Voltage Relay Protection Setting Sheet

A High Voltage relay protection setting sheet provides calculated settings for relays, including overcurrent, distance, and transformer differential protection, ensuring selectivity, sensitivity, and reliability in HV substations. Key Components of a Relay Protection Setting Sheet1.

Relay Identification and Type

Include the relay manufacturer, model, and type (e.g., SEL-311C for distance protection, SEL-787 for transformer differential)Assign a unique code for each relay to match the single-line diagram for easy identification. 2.

Measurement Transformer Ratios

Specify C

T (Current Transformer) and VT (Voltage Transformer) ratios for both primary and secondary sidesEnsure ratios match system parameters to provide accurate relay input signals. 3.

Overcurrent Relay Settings

Plug Setting Multiplier (PSM): Determines how many times the relay secondary current exceeds the pickup current; higher PSM results in faster tripping. Time Setting Multiplier (TSM): Scales the base operating time from the relay's characteristic curve to achieve proper coordination; lower TSM = faster tripping. Include instantaneous and time-delayed settings for selective tripping.

4.

Distance Relay Settings

Zone Reach: Typically, Zone 1 is set to 80–90% of line impedance; Zone 2 and 3 cover backup protection. Impedance Characteristics: Mho characteristics are preferred for phase faults; quadrilateral characteristics for phase-to-ground faults. Zero Sequence Compensation: Applied if line impedance varies or hybrid circuits are used.

5. Transformer Differential ProtectionTAP Settings: Convert secondary currents to per-unit values for each winding; ensure TAPmax/TAPmin ≤ 7. 5.

Include through-fault stability, inrush restraint, and harmonic filtering to prevent false tripping. 6.

Fault Level and Sensitivity Calculations

Calculate maximum load current, minimum fault current, and voltage levels to ensure relay sensitivity under all conditions. Include single line-to-ground, line-to-line, and three-phase fault currents. 7.

Coordination and Selectivity

Ensure upstream and downstream relays are coordinated to isolate only the faulty section. Include time-current curves and labels for each relay to visualize coordination. Adjust settings to minimize service disruption while protecting equipment.

8.

Documentation and Notes

Include single-line diagrams showing relay locations. Provide tables for all calculated settings, including PSM, TSM, zone reach, and TAP values. Note any assumptions, such as tower footing resistance, arc resistance, or compensation factors.

Practical TipsRe-evaluate settings during commissioning based on actual measured values.

Follow IE

C 60255 standards for overcurrent and IDMT relay performance. Maintain a clear record of all calculations and assumptions for future maintenance or audits. This structured setting sheet ensures reliable, selective, and fast protection of high voltage equipment, including transformers, lines, and switchgear, while minimizing unnecessary outages and equipment damage.
