800G Optical Module Technology

800G optical modules are available primarily in QSFP-DD and OSFP form factors, with options like DR8, PSM8, 2DR4, FR, and LR for varying distances and applications. Form FactorsQSFP-DD (Quad Small Form-Factor Pluggable Double Density): Compact, backward compatible with QSFP+ and QSFP28, supports high port density, suitable for short- to medium-reach applications, and uses 8 channels with PAM4 modulation.

OSF

P (Octal Small Form-Factor Pluggable): Larger module with higher thermal capacity (up to 25W TDP), ideal for high-performance deployments and easier future upgrades to 1. 6T or 3. 2T interfaces.

Key 800G Module TypesDR8 (8-channel, 100G PAM4): Short-reach, single-mode fiber, up to 500m, commonly used for intra-rack or adjacent-rack connections in data centers. PSM8 (8-channel CWDM): Supports 100m transmission, suitable for long-distance single-mode fiber and fiber resource sharing. 2DR4: Combines two 400G-DR4 links in one 800G transceiver, enabling 500m transmission without optical breakout cables, ideal for data center upgrades.

F

R (Fixed Reach) and LR (Long Reach): Designed for longer-distance transmission, typically for campus or metro networks. SR8 (Short Reach, multimode): Uses VCSEL technology, 850nm wavelength, 16 optical fibers, suitable for distances under 100m within data centers.

Applications

Hyperscale data centers: High-density, low-latency environments requiring massive throughput for AI, HPC, and cloud workloads. AI/ML clusters: Reduces network latency and improves GPU training efficiency by providing higher bandwidth than 400G deployments. Data center interconnects: Supports 800G-800G, 800G-400G, and 800G-100G links for flexible network scaling.

ConsiderationsSingle-channel rate: 100G modules are easier to implement; 200G modules require advanced optical devices and gearbox conversion. Distance and fiber type: Choose DR8, PSM8, or 2DR4 based on required reach and fiber availability. Thermal and power: OSFP modules handle higher power dissipation, while QSFP-DD is more compact for high port density.

Standards compliance: Ensure modules comply with IEEE 802. 3ck, 802. 3cu, QSFP-DD MSA, or OSFP MSA for interoperability.

800G optical modules represent the next step in high-speed data transmission, offering flexibility in form factor, reach, and channel configuration to meet the demands of modern data centers and high-performance networks.
