Function of Thai Box-Type Optical Splitter

Fiber and communications infrastructure knowledge brief Published 03 Oct 2022

Prepared for preliminary research by the ENSAA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

A Thai Box-Type Optical Splitter is a passive device that divides a single optical signal into multiple outputs, enabling efficient distribution of fiber optic signals to multiple users in FTTH and GPON networks.

Core Function

The Thai Box-

Type Optical Splitter is a passive optical component that operates without electricity, relying on the physics of light to split or combine signals. Its primary function is to distribute a single incoming optical signal into multiple output fibers according to a predefined split ratio, such as 1: 2, 1: 4, 1: 8, or 1: 32, allowing one fiber from the central office to serve multiple endpoints like homes or offices. This reduces the need for separate fibers for each user, lowering network costs and simplifying deployment.

Operational Mechanism

Inside the splitter, the optical signal travels through waveguides or fused fiber structures that manipulate light via reflection, refraction, and waveguiding. The light is divided according to the splitter's ratio, ensuring uniform power distribution across all output ports.

Thai Box-

Type splitters typically use PLC (Planar Lightwave Circuit) technology, which provides low insertion loss, high uniformity, and stable performance over a wide wavelength range. ApplicationsFTTH Networks: Distributes signals from a single fiber to multiple homes, supporting broadband, IPTV, and VoIP services.

GPO

N Networks: Enables high-density optical distribution with split ratios like 1: 8 or 1: 32, connecting multiple subscribers to a single OLT port.

LAN and CAT

V Systems: Provides signal distribution in local networks and cable TV systems.

Advantages

Passive Operation: No power required, ideal for remote or outdoor installations. Bidirectional Functionality: Can split outgoing signals and combine incoming signals for two-way communication. Compact and Durable: Housed in a protective box, suitable for outdoor or indoor deployment.

Flexible Split Ratios: Supports various network designs, including centralized and distributed splitting architectures. In summary, the Thai Box-Type Optical Splitter is essential for efficient optical signal distribution, enabling multiple users to share a single fiber while maintaining signal quality and network reliability.
