Installation of high-voltage cable trays in South Korea

High voltage cable tray installation in South Korea involves careful planning, adherence to safety standards, and coordination with local suppliers and experienced contractors. Overview of High Voltage Cable Projects in South KoreaSouth Korea has been actively developing high voltage (HV) and high voltage direct current (HVDC) projects, such as the Donghae-Singhamyeong 500 kV HVDC project, which is the largest in the country and among the highest-capacity globally.

L

S Cable & System, a leading domestic company, has extensive experience in both submarine and underground HVDC cable installations, making them a key player for large-scale HV projects. Other projects include medium-voltage HTS cables (23 kV, 50 MVA class) tested for high current and low-temperature performance, demonstrating advanced cable technologies in the region.

Cable Tray Installation Process

The installation of cable trays and ladders for high voltage systems follows a structured methodology: Material Inspection and Storage: All cable trays, ladders, and accessories must be inspected upon delivery to ensure compliance with approved specifications. Damaged or non-compliant materials are removed immediately. Trays are stored horizontally on flat surfaces with timber supports at 1-meter intervals and protected from moisture and sunlight.

Review of Shop Drawings: Approved shop drawings are reviewed to determine the layout, length, and positioning of cable trays and ladders within electrical rooms, plant rooms, and service corridors. Site Preparation: The site engineer ensures that all tools, equipment, and materials meet contract requirements. Supports, hangers, and anchor points are installed according to design specifications.

Tray and Ladder Installation: Cable trays and ladders are mounted securely, maintaining proper alignment and spacing. Supports are installed at regular intervals to handle the weight of high voltage cables. Proper grounding and earthing systems are integrated during installation.

Cable Pulling and Termination: High voltage cables are carefully pulled into the trays, avoiding sharp bends or mechanical stress. Terminations, joints, and protective systems are installed according to electrical standards. Testing and Commissioning: After installation, the system undergoes testing, including insulation resistance, continuity, and fault location checks.

Senior Authorized Personnel (SAP) may perform switching, commissioning, and verification of protective systems.

Local Suppliers and Contractors

Several South Korean companies specialize in cable trays and related products: Seoyoung Industrial Co., Ltd.: Recognized for high-quality cable trays and accessories.

DAEHAN HI MES

H Co., Ltd.: Supplies cable trays for shipbuilding and industrial applications. These suppliers provide materials suitable for both indoor and outdoor HV installations, including metal, GRP, and specialized high-temperature trays.

Safety and Standards

High voltage cable tray installations must comply with Korean Electrical Safety Standards and international best practices. Key considerations include: Proper grounding and bonding of trays and ladders. Adequate spacing to prevent overheating.

Fire-resistant materials for indoor installations. Coordination with HVDC or HTS cable specifications to ensure thermal and electrical compatibility.

Conclusion

Installing high voltage cable trays in South Korea requires detailed planning, adherence to safety standards, and collaboration with experienced contractors and local suppliers. By following structured installation procedures and leveraging domestic expertise, projects can achieve reliable, safe, and efficient HV cable management for both underground and overhead systems.
