Cable tray installation on exterior walls of buildings

Fiber and communications infrastructure knowledge brief Published 19 May 2022

Prepared for preliminary research by the ENSAA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Proper outdoor cable tray installation requires careful planning, corrosion-resistant materials, secure wall mounting, and adherence to electrical codes for safety and durability.

Planning the Route

Before installation, plan the tray route along the wall, ensuring it avoids obstructions and allows sufficient clearance for cable pulling and future maintenance. Mark horizontal and vertical runs using a chalk line or laser level, and identify locations for bends, tees, or risers to maintain smooth cable transitions.

Selecting the Right Tray Type and Material

For outdoor walls, choose corrosion-resistant materials such as galvanized steel, stainless steel, or fiberglass-reinforced plastic (FRP). Ladder trays are ideal for power cables due to ventilation and easy cable entry, while ventilated troughs or perforated trays suit control or instrumentation cables. Ensure the tray width and depth accommodate the cable count without exceeding fill ratios specified by the NEC or local codes.

Mounting and Supports

Use wall brackets or arms designed for outdoor use, spaced according to tray type and load—typically 1. 5 to 3 meters apart. Secure the tray with appropriate clamps and fasteners, ensuring it is level and straight.

Supports must handle the maximum cable load, with a typical maximum load per hanger ranging from 318 kg to 340 kg. For outdoor exposure, consider UV-resistant coatings or protective covers to prevent weather damage.

Installation Steps

Inspect and prepare materials: Verify trays, brackets, and fittings are undamaged and suitable for outdoor use. Mark support points: Align with the planned route and ensure proper spacing. Install brackets and supports: Drill into the wall using anchors suitable for the wall type (concrete, masonry, or metal).

Assemble and secure trays: Connect sections with couplers or splice plates, ensuring joints are tight and level. Grounding and bonding: Ensure the tray system is properly grounded according to NEC Article 392 to prevent electrical hazards. Cable installation: Lay cables carefully, maintaining separation for power and control circuits, and secure with cable ties or clamps.

Outdoor Considerations

Weatherproofing: Protect trays from rain, snow, and UV exposure. Slightly elevate trays or slope ends for drainage. Corrosion protection: Use galvanized or stainless steel, or FRP trays in highly corrosive environments.

Maintenance access: Ensure enough clearance for cable pulling and future inspections. By following these steps and using appropriate materials, an outdoor wall cable tray installation can be safe, durable, and compliant with electrical standards, while allowing easy maintenance and scalability for future expansions.
