How to assign VLANs to optical ports on a Huawei switch

Fiber and communications infrastructure knowledge brief Published 20 Jan 2022

Prepared for preliminary research by the ENSAA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

VLANs on Huawei switch optical ports can be configured as access, trunk, or hybrid ports using CLI commands, with PVID and allowed VLANs set according to network requirements. Step 1: Access the Switch CLIConnect to the Huawei switch via console, SSH, or Telnet. Enter system view to start configuration: CodeCopy system-view Step 2: Create VLANsDefine the VLANs you need and optionally add descriptions: CodeCopy vlan 100[Huawei-vlan100] description Sales_VLAN[Huawei-vlan100] quit vlan 200[Huawei-vlan200] description IT_VLAN[Huawei-vlan200] quit Step 3: Configure the Optical PortOptical ports are typically GigabitEthernet or 10GigabitEthernet interfaces.

Decide whether the port will be access, trunk, or hybrid: Access Port (single VLAN)CodeCopy interface GigabitEthernet0/0/1[Huawei-GigabitEthernet0/0/1] port link-type access[Huawei-GigabitEthernet0/0/1] port default vlan 100[Huawei-GigabitEthernet0/0/1] quit port link-type access: sets the port for end devices.port default vlan 100: assigns VLAN 100 to untagged frames. Trunk Port (multiple VLANs)CodeCopy interface GigabitEthernet0/0/10[Huawei-GigabitEthernet0/0/10] port link-type trunk[Huawei-GigabitEthernet0/0/10] port trunk allow-pass vlan 100 200[Huawei-GigabitEthernet0/0/10] quit port link-type trunk: allows multiple VLANs.port trunk allow-pass vlan 100 200: specifies which VLANs can pass through the trunk.

Hybrid Port (mixed tagged and untagged)CodeCopy interface GigabitEthernet0/0/2[Huawei-GigabitEthernet0/0/2] port link-type hybrid[Huawei-GigabitEthernet0/0/2] port hybrid pvid vlan 100[Huawei-GigabitEthernet0/0/2] port hybrid vlan 100 200 tagged[Huawei-GigabitEthernet0/0/2] quit port hybrid pvid vlan 100: sets the default VLAN for untagged frames.port hybrid vlan 100 200 tagged: allows tagged frames for multiple VLANs. Step 4: Configure VLAN Interface (Optional)If you need Layer 3 connectivity for the VLAN: CodeCopy interface Vlanif100[Huawei-Vlanif100] ip address 192. 168.

100. 1 255. 255.

255. 0[Huawei-Vlanif100] quit Step 5: Verify ConfigurationCheck VLAN assignments and port types: CodeCopy display vlan display port vlan display vlan: shows all VLANs and member ports.display port vlan: shows port link type, PVID, and allowed VLANs. NotesPVID: The default VLAN ID for untagged frames on access or hybrid ports.

Tagged vs Untagged: Trunk ports carry tagged frames; access ports carry untagged frames. Optical ports: Commands are the same as for copper ports; ensure the interface name matches the optical module (e.g., GigabitEthernet0/0/10 or 10GE0/0/1). By following these steps, you can configure VLANs on Huawei switch optical ports for access, trunk, or hybrid scenarios, ensuring proper segmentation and traffic isolation across your network.
