How to insert the fiber optic card into the router

You connect a fiber optic card to a router by first linking it to an Optical Network Terminal (ONT), which converts the optical signal to Ethernet, and then connecting the ONT to your router via an Ethernet cable.

Required Equipment

Optical Network Terminal (ONT): Provided by your ISP, it converts the fiber optic signal into an electrical signal your router can use. Fiber optic cable: Usually single-mode with SC/APC or SC/UPC connectors. Fiber-ready router: Ensure it has a WAN or SFP port compatible with Ethernet input.

Ethernet cable: Cat6 or higher is recommended to maintain high-speed performance.

Step-by-

Step Connection

Install the ONT: Locate the fiber wall outlet where your ISP's fiber line enters your home. Connect the fiber optic cable from the wall to the ONT's optical port. Power on the ONT and wait for the status lights to stabilize.

Connect the ON

T to the Router: Use an Ethernet cable to link the ONT's LAN/Ethernet port to the router's WAN or Internet port. Ensure the cable is securely plugged in. Power On the Router: After the ONT is active, power on your router.

Wait for the router's indicator lights to confirm a successful connection. Configure the Router: Access the router's web interface (usually via 192. 168.

0. 1 or 192. 168.

1. 1) to set up your internet connection, Wi-Fi network, and security settings.

Tips for Optimal Performance

Handle fiber connectors carefully: Avoid touching the glass tip and remove protective caps only when ready to connect.

ON

T placement: Keep it close to the fiber entry point to minimize signal loss. Use high-quality Ethernet cables: Cat6a or higher ensures you can fully utilize fiber speeds. Check compatibility: Ensure your router supports the same fiber type and connector as your ONT if using direct fiber input.

By following these steps, your fiber optic card or cable will be properly connected to your router, providing a stable, high-speed internet connection.
