Overheat Relay Protector Specifications and Models

Fiber and communications infrastructure knowledge brief Published 16 May 2025

Prepared for preliminary research by the ENSAA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Overheat relay protectors safeguard motors from overheating by monitoring current or temperature and disconnecting the circuit when limits are exceeded, with models available in thermal, thermistor, and electronic types. Types of Overheat Relay Protectors1. Thermal Overload Relays: These relays use heat-sensitive elements to mimic motor heating.

They are widely used in industrial applications for standard motor protection. Bimetallic strips bend predictably when heated by motor current, triggering a mechanical trip to disconnect the motor. They can have manual or automatic reset options and cover current ranges from 0.

11–16 A and motor power from 0. 06–5. 5 kW depending on the model (Schneider Electric).

2.

Thermistor-

Based Relays: Thermistor relays, such as Siemens SIRIUS 3RN2, monitor the motor winding temperature directly using PTC sensors. When the rated temperature is reached, the resistance increases sharply, causing the relay to trip. These relays are suitable for hazardous areas and provide precise protection even under heavy starting or inadequate cooling conditions.

3. Electronic Relays: Electronic or microprocessor-based relays offer precise monitoring of current and temperature, often with adjustable trip points, diagnostics, and communication capabilities. They are ideal for high-precision or critical industrial applications.

Key Specifications

Current Range: Typically 0. 1–80 A for ABB TA series; 0. 11–16 A for Schneider Electric thermal relays.

Motor Power Coverage: From small motors (0. 06 kW) to heavy-duty industrial motors (up to 5. 5 kW or higher).

Reset Modes: Manual reset, automatic reset, or remote reset depending on the model. Mounting: Many relays mount directly onto contactors for compact installation (ABB TA2X series). Protection Features: Overheating, phase loss, abnormal load, and in some models, hazardous area compliance (ATEX).

Popular ModelsABB TA Series: TA2X range for 0. 1–80 A, reliable and flexible, mounts on ABB contactors. Motogard Series 150: Uses PTC thermistors with snap-action response for rugged environments.

Siemens SIRIU

S 3RN2: Thermistor-based, direct winding temperature monitoring, ATEX-approved. Schneider Electric Thermal Relays: Manual or automatic reset, 0. 11–16 A, suitable for small to medium motors.

Selection Considerations

When choosing an overheat relay protector, consider: Motor type and power ratingCurrent range and trip accuracyReset mechanism (manual vs automatic)Environmental conditions (hazardous areas, temperature extremes)Mounting compatibility with existing contactors or motor starters. By matching the relay type and specifications to your motor and operational requirements, you can ensure reliable protection, prevent downtime, and extend motor lifespan.
