Core Switch and Gateway

A core switch can function as the gateway for VLANs or subnets, handling routing and IP address assignment for connected devices. Role of a Core Switch as a GatewayA core switch, especially a Layer 3 switch, can serve as the default gateway for multiple VLANs or subnets in a network. It provides routing and forwarding for traffic between subnets and to external networks, effectively acting as the exit point for devices in each VLAN.

In campus or enterprise networks, the core switch often connects to aggregation and access switches, centralizing traffic management and improving reliability.

Gateway IP Configuration

For each VLAN or subnet, the core switch typically hosts a Switched Virtual Interface (SVI) with an IP address that serves as the gateway. For example, if a Layer 2 access switch has devices in the 172. 20.

10. 0/24 subnet, the core switch would have an SVI like 172. 20.

10. 1, which becomes the default gateway for all devices in that subnet. Access switches themselves do not usually act as gateways; they forward traffic to the core switch for inter-VLAN routing.

DHCP and IP Assignment

Core switches can also function as DHCP servers, assigning IP addresses to devices in their respective VLANs. In some architectures, access controllers (ACs) or aggregation switches may handle DHCP for APs or specific segments, but the core switch remains the central routing point. This ensures consistent IP management and simplifies network troubleshooting.

Best Practices

Layer 3 Core Switch: Use a Layer 3 switch at the core to handle routing efficiently.

Separate Management and Service VLA

Ns: Avoid using VLAN 1 for management or service traffic to prevent conflicts.

SV

I per VLAN: Assign a unique SVI on the core switch for each VLAN/subnet to act as the gateway. Edge Routing: For WAN or internet access, the core switch may point to an external router as its next-hop gateway. Scalability: In large networks, placing gateways at the core simplifies expansion and centralizes traffic control.

In summary, the core switch can and often should act as the gateway for connected VLANs and subnets, providing Layer 3 routing, DHCP services, and centralized network management while subordinate switches handle local device connectivity.

Proper SV

I configuration and VLAN separation are key to maintaining network stability and performance.
