Electrical distribution boxes were installed in the evacuation routes

Fiber and communications infrastructure knowledge brief Published 28 Apr 2023

Prepared for preliminary research by the ENSAA knowledge desk. Confirm optical interfaces, port or core capacity, electrical input and output, enclosure protection, thermal design and installation limits against current standards and product documentation.

Installing electrical distribution boxes in protected escape routes is generally restricted and must comply with fire safety regulations to avoid obstructing evacuation and increasing fire risk.

Regulatory Considerations

Protected escape routes are designed to be fire and smoke-resisting and should ideally contain no combustible materials to ensure safe evacuation during emergencies (BS 7671: 2018+A2: 2022, Appendix 13). Electrical equipment, including distribution boxes, is typically restricted to essential systems such as emergency lighting, fire detection, and alarm systems (BS 7671, 422. 2).

Non-essential electrical installations can compromise the fire sterility of the route and may hinder evacuation or firefighting efforts.

Fire Safety Requirements

Any wiring or electrical equipment installed in these routes must meet strict fire performance standards. Cables should be non-flame-propagating with limited smoke production, and containment systems must be fire-resistant to prevent collapse during a fire (BS 7671, 422. 2.

1; BS EN 60332; BS EN 61034-2). Non-metallic supports alone are insufficient, and metallic or certified fire-resistant supports are required to secure cables and equipment.

Practical Implications

Distribution boxes should not obstruct the escape path or reduce the minimum width of the route. Only boxes necessary for emergency or safety systems may be installed. If standard low-voltage distribution boxes are used, they must be enclosed in fire-resistant containment to comply with regulations.

Hospitals or specialized buildings may have additional requirements for essential electrical services in escape routes.

Summary

While electrical distribution boxes can technically be installed in evacuation routes, they must be limited to essential safety functions, properly enclosed, and supported with fire-resistant materials. Any installation must comply with BS 7671: 2018+A2: 2022 and local fire safety codes to ensure that the escape route remains safe, unobstructed, and fire-sterile during emergencies.
