Optical Implementation Using Ieee 1394 B Rev A

Two optical fibers are fused together using a coupler

At the most basic level, a fused fiber optic coupler consists of two fibers that are connected together. Once an understanding of this has been obtained, some of the principals of operation will be made clear at once (bi-directionality, for example). A fused coupler basically consists of two, parallel optical. Fused couplers are used to split optical signals between two fibers, or to combine optical signals from two fibers into one fiber. This method provides a simple, rugged, and compact method of splitting and combining optical signals. Directional 2 × 2 couplers (see Figure 1) are usually used for. Two or more fibers can be thermally tapered and fused so that their cores come into intimate contact over some length of a few centimeters, for example.
